Typical application:





pdf-download 139669-1  Art. nr. 139669

> Zum Online Shop

Highlights:





? Up to 1200Mbps powerline data transmission rate



? Supports MIMO



? Compatible with other HomePlug AV technologies



? Secure communication and protect your data by clicking one button



? 1 gigabit ethernet ports



? Internal PoE IEEE802.3at Injector support max. 30W for example IP-Cameras / ALL-SG82xxPD Switches etc.







Introduction



ALL1681203 Smart Link HomePlug AV2 1200Mbps Ethernet Adapter embarks on a concept of No New Wires data communications, and it transforms your in-house powerline into a networking infrastructure. It provides SmartLink Plus coupling to the Line-Neutral pair and the Line-Ground pair of the AC mains. It successfully reduces "dead spots", increases throughput and network coverage within a home. Surf the Internet and share data at the speed up to 1Gbps (PHY rates) through powerline, And Built-in PoE Injector can provide 55V/48V classification power via CAT5E / CAT6 ALL1681203 Smart Link HomePlugAV2 engine is Qualcomm Atheros QCA7500 chip set , It features faster processing power, Fast Ethernet host interfaces and an enhanced analog front end. The solution is compliance with IEEE1901 , Homeplug AV and Homeplug AV2, hence allowing hassle free compatibility with existing Homeplug AV2 devices and other suppliers of IEEE1901 PLC (Powerline Line Communication) devices and IEEE 802.3at /af compliant Midspan or Endpoint (Option) PSE.



Technical Details:







Element





Spezifikation





Chipset:





Qualcomm QCA7500 + QCA8334





Standards:





? IEEE 1901, IEEE 1905.1 and HomePlug AV                Compliant



? HomePlug AV2 Compliant



? AV2 30MHz and 67MHz MIMO profi les



? AV2 30MHz and 67MHz SISO profi les



? Power Save mode



? Co- existence with HomePlug 1.0/Turbo Nodes



? Compliant to ErP 2013 directive



? IEEE 802.3 10/100/1000 Ethernet(1200Mbps)





Brutto data rate Powerline:





up to 1200Mbps





Frequency band:





2MHz to 67,5 MHz





Access-Methode Powerline:





Priority-based CSMA/CA channel access





Quality of Service:







  • Priority-based CSMA/CA channel access schemes maximize effi ciency and throughput
  • Integrated Quality of Service (QoS) Enhancements
  • Supports IGMP managed multicast session



Modulation:







OFDM 4096/1024/256/64/16/8 QAM, QPSK, BPSK, ROBO, und Mini-ROBO Modulation Schema





Powerline interface:





Type F earthing contact connector (DE), Type C/E (FR)





Network interface:





1x RJ45 10/100/1000Mbit





IGMP:







  • Support IGMP managed multicast sessions
  • IGMP snooping with multicast to multiple unicast support
  • IGMP/MLD Adressfiltering



Nodes/Clients:





max. 15 devices





Security support:





128bit AES Link encryption with key management



(aktivated via Simple Connect button)





LED indicators:





Power LED

PowerLine Link/ACT Status LED

2x Ethernet Link/ACT Status LED





Power supply:





Type F earthing contact connector (DE), Type C/E (FR) Switch mode 110VAC to 240VAC



Power over Ethernet:

Data PIN´s: 1,2 & 3,6

Power: 4,5 & 7,8

Max. 30 PoE IEEE802.3at 48V



Operating systems:





all TCP/IP operating systems





Operating systems for



configurationsoftware:









Windows® XP32bit, Windows® Vista32/64bit, Windows®7 32/64bit







Housing:





synthetic housing





Environment:





Temperature operating: 0 ~ 40 °C



Humidity operating: 30% ~ 80% (non condensing)



Temperature storage: -25 ~ 70 °C



Humidity storage: 30% ~ 95% (non condensing)





Marks:





CE, RoHS





Dimensions:





115 x 65 x 30mm





Weight:





300g (only device)







Package content:





1x ALLNET ALL1681203

1x RJ45 patch cable 1m

1x CD-ROM with manual & software
