Der Bedarf an mehr Speicherplatz und Möglichkeiten zur Dateifreigabe im Netzwerk steigt heutzutage speziell im Unternehmensumfeld immer rasanter an! Datenmengen, an die man vor wenigen Jahren noch nicht einmal gedacht hat, müssen heute sicher und schnell verfügbar sein. Aus diesem Grund stellt ALLNET eine brandneue NAS-Tower-Serie vor – mit 6, 8 und 10 Einschüben. Jedes einzelne Modell wurde dabei auf größtmögliche Flexibilität ausgelegt und für spezielle Business-Netzwerkarchitekturen optimiert. ALL-NAS800: Perfekt abgestimmt Das vor einiger Zeit vorgestellte ALL60900 19“ Rack NAS RAID System wurde von der Presse mit offenen Armen aufgenommen; ALLNET erfreute sich einer Vielzahl positiver Rückmeldungen. Mit einer kleinen Ausnahme: Wie sieht es aus, wenn ich mehr Leistung in einem Tower-Formfaktor benötige? Problem gelöst! Der ALL-NAS800 ist ein Tower-NAS mit 8 Einschüben, der mit einem Intel® Core ™ i3 und 4 GB RAM aufwartet. Ein perfektes Gerät für anspruchsvolle geschäftliche Anwendungen, bei denen Aufgaben häufig und gleichzeitig bei hoher Geschwindigkeit abgearbeitet werden müssen. Hosting von Virtual Machines, Anwendungsserver für dutzende Benutzer, Web-Hosting, härtester Sicherungseinsatz, erweiterte RAID-Stufen und so weiter. Die neue Tower-NAS-Serie von ALLNET vereinigt das Beste vom Besten in einem überaus praktischen Format. Sämtliche NAS der neuen Tower-Serie sind für 10 Gb Ethernet vorbereitet und beugen durch USB 3.0-Kommunikation möglichen Flaschenhals-Problemen vor. Durch HDMI-Ausgang, komfortable Touchpanel-Bedienung, 10GBASE-T eignet sich diese Serie optimal für anspruchsvollstes Datenmanagement mit 10 GbE-Datentransfergeschwindigkeiten. Technische Daten 1.Hardware Platform Item | Spec | Processor | Intel® Core™ i3 2120 3.3GHz | System Memory | 4GB DDR3 | LAN Interface (PCI-e) | RJ-45x2: Intel 82574L 10/100/1000 BASE-TX Auto MDI/MDI-X WOL supported PCI Express 8 lane slot x2 | USB Interface | USB 2.0 host port x4 (Type A, one has power always on function) (front x2, back x2) USB 3.0 host port x4 (front x2, back x2) | OLED | Displays system status and information (Multilingual) | Disk Interface | 8 x SATA for internal | Power Supply | Single 400W power supply (80plus) | System Clock | Battery-backed up system clock | Power Management | Auto power on after shutdown due to power loss | Buzzer | Adjustable frequency alarm | Touch Panel | Power button OLED button (ENT, ESC, UP, DOWN) | Environment | Temperature: 0°C to 40°C Humidity: 0 ~ 80 % R.H. (Non-condensing) | Chassis | Tower base | Dimensions (HxWxD) | 380.4 x 235 x 282.6 (mm) | Compatibility | 10GbE PCI-e card USB/slim CD/DVD/Blu-Ray drive UPS | 2. Software Functions
RAID | RAID Modes | RAID 0, 1, 5, 6, 10, 50, 60 and JBOD | Supported Features | Auto-Rebuild, Hot-Swap, Dedicated / Global Hot Spare, Online RAID Migration / Expansion, | RAID Volume Encryption | AES256bit | Disk | Power Management | Available spin-down while idle setting | Bad Block Scanning | Supported | SMART Info / Test | Supported | Disk Roaming | Supports volume-based roaming to other ALLNET NAS | Network | Configuration | Fixed IP address, dynamic IP address | IP Sharing Mode | Can be enabled/disabled | Transport Protocols | TCP/IP/AppleTalk | File Protocols | SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP | Link Aggregation | Load balance, Failover, 802.3ad, Balance-XOR, Balance-TLB, Balance-ALB | TCP/IP | IPV6 & IPV4 | Data Access | Client OS Support | Windows 2000/XP/2003/Vista/7, UNIX/Linux, Mac OS X | FTP / Secure FTP | Built-in FTP / Secure FTP server with bandwidth control | TFTP | Users can download and upload files with TFTP programs | Printer Server (IPP) | Supports USB printers Supports a wide range of IPP printers Client can manage print tasks (list/delete) via web user interface | Data Backup | Client Side Backup Software | Backup Utility (Windows/Mac OS X) | Rsync Backup | Rsync replicates data between two systems (via Rsync module) | DVD Backup | Supported | Mac OS X Time Machine | Supported | Block Level Access | iSCSI Target/Initiator | Supports Microsoft/Mac OS X/Linux initiators and ALLNET NAS targets | iSCSI Thin Provisioning | Supported | MPIO / MCS / Clustering | Supported | SCSI3 persistent group reservation | Supported | Power Management | Scheduled Power On/Off | Supported | Volume Management | Multiple RAID | Supported | Multiple File System Selectable | EXT3/EXT4/XFS | Multimedia Support | iTunes Server | Supports AAC, MP3 w/ID3 tag and WAV | User Authentication | Local User / Group | Supports built-in user accounts and groups | Windows ADS/LDAP | Supported | On-line User list | Supported | Access Guard | Supports Black & White list/IP Filter | File System | Type | Journaling File System | Language Support | Unicode Support | Authorization (ACL) | “Read”, “write”, or “deny” privileges to individual users or groups in folders and sub-folders | User Quota/ User Quota Sync | Supported | Administration | User Interface | Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish and Portuguese | Utility Program | MS Windows Setup Wizard Supports Windows 2000/XP/2003/Vista/7 Mac OS X Setup Wizard | Email Notifications | Sends system messages via email to the system administrator | SNMP Trap | System information trap out | SSH | Supported | Downloads Back |
