CPU

Model: Rockchip RK3588S

Number of Cores: Quad-core ARM Cortex-A76 & Quad-core Cortex-A55 CPU

Frequency: 4 x Cortex-A76 up to 2.4GHz & 4 x Cortex-A55 up to 1.8GHz

GPU

Mali-G610 MP4, compatible with OpenGLES 1.1, 2.0, and 3.2, OpenCL up to 2.2 and Vulkan1.2

VPU

8K@60fps H.265 and VP9 decoder, 8K@30fps H.264 decoder, 4K@60fps AV1 decoder

8K@30fps H.264 and H.265 encoder

NPU

6TOPs, supports INT4/INT8/INT16/FP16

Memory

RAM: 64-bit 4GB/8GB LPDDR4X at 2133MHz

Storage

MicroSD Slot: MicroSD x1, support up to SDR104 mode

Flash: 32GB eMMC, at HS400 mode

PCIe: M.2 M-Key, PCIe2.1 x1, support NVME, PCIe WiFi etc

Onboard M3 PCB nut for mounting M.2 2280 module

Connectivity

Ethernet: Native Gigabit Ethernet x1, RTL8211F-CG chip

PCIe 2.5G Ethernet Ethernet x1, RTL8125BG chip

Video Output

HDMI: compatible with HDMI2.1, HDMI2.0, and HDMI1.4 operation

support up to 7680x4320@60Hz

Support RGB/YUV(up to 10bit) format

USB

USB 3.0 Host x1: USB Type A

USB 2.0 Host x1: USB Type A

USB-C x1: Power input(5V/9V/12V/20V), support PD

Pin-header

GPIO: 30-pin 2.54mm header connector

up to 1x SPI, 3x UARTs, 3x I2Cs, 2x SPDIFs, 1x I2Ss, 3x PWMs, 20x GPIOs

Debug: Debug UART x1 via 3 Pin 2.54mm header, or on-board USB-C to UART

LED

SYS LED(Red) x1

WAN LED(Green) x1

LAN LED(Green) x1

LED1(Green) x1

Button

MASK Button x1 for eMMC update

User Button x1

Others

RTC Battery: 2 Pin 1.27/1.25mm RTC battery input connector for low power RTC IC HYM8563TS

Working Temperature: 0? to 70?

Power

USB-C, support PD, 5V/9V/12V/20V input

OS Support

FriendlyWrt 21.02

FriendlyWrt 22.03

Android 12 Tablet

Android 12 TV

FriendlyCore Lite 20.04

Debian 10 Desktop

Debian 11 Desktop

Ubuntu 22.04 Desktop

Kernel version

Linux-5.10-LTS

U-boot-2017.09

PCB

8 Layer

Weight

53.1g(without Case) / 260g(with Case)

Dimension

62x90x1.6mm (without Case) / 68x94.5x30mm (with Case)
