VDSL2 Bridge Modem - DSLAM Required

ALLNET ALL4781-VDSL2-SFP is a VDSL2 SFP modem that interconnects with Gateway Processor by using a MSA (MultiSource Agreement) compliant hot pluggable electrical interface. The DSL chipset inside the VDSL2 SFP modem supports all VDSL2 profiles that defined by ITU-T G.993.2, andVDSL. Compliancy with G.994.1 and G.997.1 standards, ensures its interoperability with all existing broadband network services. Furthermore, ALLNET ALL4781-VDSL2-SFP also features the latest ITU standards such as G.inp (G.998.4) and G.vector (G.993.5).

As broadband access technology has evolved rapidly, Service Providers need to upgrade their broadband network service every few years. Traditionally, Service Providers have replaced the entire CPE device in order to provide subscribers with faster Internet services. Not only does it increase their CAPEX and OPEX but also wastes resources and increase inventories. Leveraging ALLNET ALL4781-VDSL2-SFP VDSL2 SFP series in Service Providers’ product portfolio will help them significantly reduced the software porting and testing effort and shorten their product time-to-market.

ALLNET ALL4781-VDSL2-SFP VDSL2 SFP modem realizes the modulation of VDSL2 broadband access. It can be integrated with routers, switches or residential gateways that are equipped with a SFP type of WAN interface. There’s no more need for Service Providers to maintain more than one type of CPE device in the field or in the warehouse, moreover, this also can give them the possibility to future upgrade. Users can upgrade to any broadband access data rate easily only by plugging in different type of WAN SFPs into the same internet box.

VDSL2 Bridge Modem



pdf-download 141114-1  Art. nr. 141114

> Zum Online Shop

Highlights:

  • Support all VDSL2 standards defined in ITU-T G.993.2, G.994.1, G.997.1.
  • MSA compliant hot pluggable electrical interface / SFP-Slot
  • Support G.inp (G.998.4) and G.vector (G.993.5)



ALLNET ALL4781-VDSL2-SFP is a VDSL2 SFP modem that interconnects with Gateway Processor by using a MSA (MultiSource Agreement) compliant hot pluggable electrical interface. The DSL chipset inside the VDSL2 SFP modem supports all VDSL2 profiles that defined by ITU-T G.993.2, andVDSL. Compliancy with G.994.1 and G.997.1 standards, ensures its interoperability with all existing broadband network services. Furthermore, ALLNET ALL4781-VDSL2-SFP also features the latest ITU standards such as G.inp (G.998.4) and G.vector (G.993.5).



As broadband access technology has evolved rapidly, Service Providers need to upgrade their broadband network service every few years. Traditionally, Service Providers have replaced the entire CPE device in order to provide subscribers with faster Internet services. Not only does it increase their CAPEX and OPEX but also wastes resources and increase inventories. Leveraging ALLNET ALL4781-VDSL2-SFP VDSL2 SFP series in Service Providers? product portfolio will help them significantly reduced the software porting and testing effort and shorten their product time-to-market.



ALLNET ALL4781-VDSL2-SFP VDSL2 SFP modem realizes the modulation of VDSL2 broadband access. It can be integrated with routers, switches or residential gateways that are equipped with a SFP type of WAN interface. There?s no more need for Service Providers to maintain more than one type of CPE device in the field or in the warehouse, moreover, this also can give them the possibility to future upgrade. Users can upgrade to any broadband access data rate easily only by plugging in different type of WAN SFPs into the same internet box.









Technical Details:

Hardware

RJ-45 female connector (Fully compatible with RJ-11 male connector)

SERDES connect to host

LED 1 (CO/ CPE indicator)

LED 2 (PWR/ Link Status indicator)

Software

Self Boot & Managed by Internal Flash

Linux driver for managed devices

Power Requirement

3.3v , 700mA

Environment

Operating Temperature

-20 ~ +75°C

Storage Temperature

-40 ~ +85°C

Operating Humidity

5% to 90%

(non-condensed)

Storage Humidity

5% to 95%

(non-condensed)

ESD Standards

Contact: +/-4KV Air:+/-8KV (EN 61000-4-2)

Radiated RFI Standards

Strength:10V/m (EN 61000-4-3)

EFT/BURST Standards

Power:2KV Signal:1KV (EN 61000-4-4)

Surge Immunity Standards

Power:2KV Signal:1KV (EN 61000-4-5)

Marks

CE / FCC
